Passive CWDM Double Fiber Mux & Demux Module 8CH (1470-1610nm) LC/UPC LGX BOX

  • Product Details
  • Company Profile

Passive CWDM Double Fiber Mux & Demux Module 8CH (1470-1610nm) LC/UPC LGX BOX

8 Channels 1470 to 1610nm LC/UPC Dual Fiber CWDM MUX DEMUX LGX BOX

Product Details


Operating Wavelength8 Channels 1470-1610nmChannel Space20nm
PassbandITU±6.5nmInsertion Loss≤2.4dB
Directivity≥50dBReturn Loss≥45dB
Monitor PortNoneFiber TypeSMF-28e or Customer Specified
Adjacent Channel Isolation≥30dBNon-adjacent Channel Isolation≥40dB
Polarization Dependent Loss≤0.2dBPolarization Mode Dispersion≤0.1ps
Maximum Optical Power500mWDimensions (HxWxD)20.2x203x197mm
Operating Temperature-20°C~+70°CStorage Temperature-40°C~+85°C

Quality Assurance

Excellent quality is the foundation of FIBER MALL' s survival and development. Our operation team are experts with many years' experience in optical communication industry. Our manufacturers are first-class manufacturers in the industry. Many of them have the qualification of OEM for first-class system equipment manufacturers.
Quality Certification
We control the quality of our products, including our strict qualification of manufacturers, quality control process and production technology, and compliance with certification and safety standards. At present, our products meet the industry standards and mainstream quality certification, such as ISO 9001, CE, RoHS, FCC, etc.
